SEM

NEW SEM 520F

$39,000.00 USD

Oferta Agotado

Item	Specification
Model	SEM 520F
Operating Weight	20,000 kg
Overall Dimensions (L×W×H)	6,370×2,310×3,200 mm
Drum Width	2,130 mm
Engine Model	Weichai WP6G175E20
Engine Manufacturer	Weichai
Rated Power	129 kW (173 HP) @ 2,000 rpm
Emission Standard	China Stage 2/EPA Tier 2
Transmission	Hydrostatic, 2 forward/2 reverse gears
Max. Travel Speed	8.5 km/h
Min. Travel Speed	2.98 km/h (1st gear); 5.88 km/h (2nd gear)
Vibration Frequency	28.5 Hz
Amplitude (High/Low)	2.05/1.15 mm
Centrifugal Force (High/Low)	380/280 kN
Static Linear Load	461 N/cm
Steering Angle	±33°
Oscillation Angle	±12°
Min. Turning Radius (Inside Drum Edge)	6,350 mm
Max. Gradeability (Vibration On/Off)	30%/34%
Fuel Tank Capacity	262 L
Tire Size	20.5-25 12PR
Hydraulic System Pressure	16 MPa
