NEW SEM 658F

NEW SEM 658F

$45,000.00 USD
$45,000.00 USD
Oferta Agotado

SEM 658F Wheel Loader Core Parameters (English)

Item Parameter Unit
Model SEM 658F -
Energy Type Electric -
Operating Weight 17200 kg
Rated Load Capacity 5500 kg
Bucket Capacity Range 2.7-5.0 m³
Engine Model WP10HG220E475 -
Rated Power 162 kW
Rated Speed 2200 r/min
Engine Displacement 9.5 L
Transmission Model TR200 -
Transmission Gears Forward 4 / Reverse 4 -
Travel Speed (F1/F2/F3/F4/R1/R2/R3/R4) 7.9/14.0/24.5/38.5 / 7.9/14.0/24.5/38.5 km/h
Maximum Traction Force 170 kN
Bucket Breakout Force 178 kN
Overall Dimensions (L×W×H) 8616×3200×3465 mm
Wheelbase 3350 mm
Unloading Height (at 45° Dump Angle) 3111 mm
Unloading Reach 1369 mm
Minimum Turning Radius (Bucket Outer Edge) 6813 mm
Steering Angle ±35 °
Hydraulic System Working Pressure 16 MPa
Brake System Type Air-over-oil caliper disc (service); Internal expanding drum (parking) -
Emission Standard China IV
