| Model |
SEM 920F Motor Grader |
| Operating Weight |
15,476 kg (standard configuration with ROPS cab, operator, full fuel tank, front and rear counterweights and standard tires) |
| Engine Model |
SDEC SC7H200.2G2 (6-cylinder, 4-stroke, turbocharged, water-cooled diesel engine) |
| Displacement |
6.5 L |
| Rated Net Power |
147 kW (200 hp) @ 2,200 rpm (ISO 9249) |
| Transmission Model |
Hangchi 6WG180 (6 forward gears, 3 reverse gears) |
| Max Travel Speed |
40 km/h (forward), 25 km/h (reverse) |
| Blade Width |
3,974 mm |
| Max Blade Lift Height |
475 mm |
| Max Cutting Depth |
715 mm |
| Max Drawbar Traction |
87 kN |
| Frame Articulation Angle |
20° (left/right) |
| Min Turning Radius |
7.8 m |
| Wheelbase |
5,647 mm |
| Overall Dimensions (L×W×H) |
11,100 × 2,630 × 3,140 mm |
| Hydraulic System |
Load-Sensing Hydraulic System |
| Max Hydraulic Pressure |
16 MPa |
| Fuel Tank Capacity |
220 L |
| Hydraulic Tank Capacity |
80 L |
| Tire Specification |
17.5-25 12PR |
| Emission Standard |
China Non-road Stage IV |
