| Engine |
Model |
Cat C2.4 DI (4-cylinder, 2.4 L / 146 cu in displacement) |
|
Gross Power (SAE J1995) |
45.7 hp (34.1 kW) @ 2400 rpmCat
|
|
Net Power (ISO 9249/SAE J1349) |
41.7 hp (31.1 kW) @ 2400 rpmCat
|
| Operating Weight |
Standard (with cab, steel tracks, 0.22 m³ bucket, operator, full fuel) |
11,905 lb (5,400 kg)Cat
|
|
With Canopy |
11,503 lb (5,218 kg) (approx., standard stick) |
| Digging Performance |
Max Dig Depth |
146.5 in (3,720 mm) |
|
Bucket Digging Force |
7,868 lbf (35 kN) |
|
Stick Digging Force |
6,116 lbf (27.2 kN) |
| Travel |
Speed (Low/High) |
2.8 mph (4.5 km/h) / 4.3 mph (6.9 km/h) |
|
Gradeability |
25° |
| Hydraulics |
System Pressure |
3,553 psi (23,000 kPa) |
| Fuel Capacity |
20.6 gal (78 L) |
