| Engine |
Model |
Cat C2.4 DI Turbo (4‑cylinder, 2.4 L / 146 cu in displacement) |
|
Gross Power (SAE J1995) |
41.7 hp (31.1 kW) @ 2200 rpm |
|
Net Power (ISO 9249/SAE J1349) |
38.5 hp (28.7 kW) @ 2200 rpm |
| Operating Weight |
Standard (with cab, steel tracks, 0.21 m³ bucket, operator, full fuel) |
13,228 lb (6,000 kg) (approx.) |
|
Canopy config (standard) |
12,787 lb (5,800 kg) (approx.) |
| Digging Performance |
Max Dig Depth |
13 ft 5 in (4,100 mm) |
|
Max Reach (ground level) |
21 ft 3 in (6,470 mm) |
|
Bucket Digging Force |
8,598 lbf (38.2 kN) |
|
Stick Digging Force |
6,719 lbf (29.9 kN) |
| Travel |
Speed (Low/High) |
2.8 mph (4.5 km/h)/4.3 mph (6.9 km/h) |
|
Gradeability |
30° |
| Hydraulics |
System Pressure |
3,553 psi (24,500 kPa) |
|
Main Flow |
21.1 gpm (80 L/min) |
| Fuel Capacity |
28.5 gal (108 L) |
