| Engine |
Model |
Mitsubishi 4M40E1 (4-cylinder, 2.8 L / 173 cu in displacement) |
|
Gross Power |
55 hp (41 kW) @ 2200 rpm |
|
Net Power |
54 hp (40.3 kW) @ 2200 rpm |
| Operating Weight |
Standard (cab, steel tracks, 0.31 m³ bucket, operator, full fuel) |
15,895 lb (7,210 kg) |
| Digging Performance |
Max Dig Depth |
13 ft 6 in (4,110 mm) |
|
Max Dig Reach (ground level) |
20 ft 10 in (6,340 mm) |
|
Bucket Digging Force |
11,371 lbf (50.6 kN) |
|
Stick Digging Force (Standard) |
8,418 lbf (37.4 kN) |
| Travel |
Speed (Low/High) |
3.3 mph (5.2 km/h)/5.2 mph (8.4 km/h) |
|
Gradeability |
70% (approx. 35°) |
| Hydraulics |
System Pressure (Equipment/Travel/Swing) |
3,980 psi (27,400 kPa)/4,550 psi (31,400 kPa)/2,840 psi (19,600 kPa) |
|
Swing Speed |
10 rpm |
| Fuel Capacity |
35.7 gal (135 L) |
