| Engine |
Model |
Cat C3.3B (4‑cylinder, 3.33 L / 203.2 cu in displacement) |
|
Gross Power (ISO 14396) |
66.6 hp (49.7 kW) @ 2400 rpm |
|
Net Power (ISO 9249/SAE J1349) |
65 hp (48.5 kW) @ 2400 rpm |
| Operating Weight |
Standard (cab, rubber tracks, 0.37 m³ bucket, operator, full fuel, auxiliary lines) |
18,519 lb (8,400 kg) |
| Digging Performance |
Max Dig Depth |
13 ft 7 in (4,150 mm)Cat
|
|
Max Dig Reach (ground level) |
21 ft 1 in (6,430 mm) (approx.) |
|
Bucket Digging Force |
13,534 lbf (60.2 kN) |
|
Stick Digging Force (Standard) |
8,992 lbf (40.1 kN) |
| Travel |
Speed (Low/High) |
1.7 mph (2.8 km/h) / 3.2 mph (5.1 km/h) |
|
Max Traction Force (Low/High Speed) |
14,500 lbf (64.5 kN) / 8,408 lbf (37.4 kN) |
|
Gradeability |
30° |
| Hydraulics |
System Pressure |
4,060 psi (28,000 kPa) (approx.) |
|
Swing Speed |
10 rpm (approx.) |
| Fuel Capacity |
39.6 gal (150 L) (approx.) |
