DOOSAN

USED DOOSAN DX150LC-9C

$18,000.00 USD

Oferta Agotado

Category	Specification Item	Parameter Value
Basic Specification	Model	DX150LC-9C
	Operating Weight	14100 kg
	Standard Bucket Capacity	0.58 m³
	Standard Boom Length	4600 mm
	Standard Arm Length	2500 mm
	Track Shoe Width	600 mm
	Ground Contact Pressure	36 kPa
Engine System	Engine Model	Doosan DL06, 6-cylinder inline turbo diesel
	Rated Power	74 kW @1900 rpm
	Total Displacement	5890 cc
	Bore × Stroke	100 mm × 125 mm
Hydraulic Performance	Bucket Breakout Force	100.9 kN
	Arm Breakout Force	59.8 kN
	Main System Working Pressure	310 bar
	Total Main Pump Flow	2×114 L/min
Travel & Swing	High Travel Speed	5.04 km/h
	Low Travel Speed	3.01 km/h
	Swing Speed	10.1 rpm
	Max Gradeability	70%
Overall Dimension	Overall Length	7662 mm
	Overall Width	2530 mm
	Cab Top Height	2773 mm
Working Range	Max Digging Depth	5625 mm
	Max Vertical Digging Depth	4650 mm
	Max Digging Radius	8305 mm
	Max Digging Height	8750 mm
	Max Dumping Height	6300 mm
Tank Capacity	Fuel Tank Volume	267 L
	Hydraulic Oil Tank Volume	145 L
Standard Accessory	Factory Configuration	Pre-installed hydraulic breaker piping
