| Model |
Hitachi EX1200-7 (Backhoe) |
| Operating Weight |
117,000 kg |
| Standard Bucket Capacity (ISO Heaped) |
5.2 m³ (Backhoe) |
| Overall Dimensions (L×W×H) |
15,400 × 5,410 × 4,350 mm |
| Track Shoe Width |
700 mm |
| Track Gauge |
3,900 mm |
| Min. Ground Clearance |
1,020 mm |
| Undercarriage Width |
4,600 mm |
| Engine Model |
Cummins QSK23-C (8-cylinder, turbocharged, water-cooled) |
| Rated Power |
567 kW (760 HP) @ 1,800 rpm |
| Displacement |
23.15 L |
| Emission Standard |
FCO / Tier 4 Final / Stage V |
| Fuel Tank Capacity |
1,470 L |
| Hydraulic System Pressure |
31.9 MPa |
| Max Digging Depth (Backhoe) |
9,400 mm |
| Max Digging Radius (Ground Level) |
15,400 mm |
| Max Digging Height |
12,410 mm |
| Max Dumping Height |
9,050 mm |
| Bucket Digging Force |
569 kN |
| Arm Digging Force |
438 kN |
| Max Traction Force |
707 kN |
| Travel Speed (Low/High) |
2.4 / 3.5 km/h |
| Swing Speed |
5.2 rpm |
| Gradeability |
35° (70%) |
| Ground Pressure |
145 kPa |
