| Model |
Hitachi EX5500‑5 |
| Operating Weight |
518,000 kg
|
| Standard Bucket Capacity (ISO Heaped) |
27.0 m³ |
| Max Bucket Capacity |
30.7 m³ |
| Overall Dimensions (L×W×H) |
20,100 × 7,400 × 8,600 mm |
| Track Shoe Width |
1,400 mm |
| Track Gauge |
6,000 mm |
| Min. Ground Clearance |
1,100 mm |
| Track Length on Ground |
7,000 mm |
| Engine Model |
Cummins QSK45‑C (Twin Engine) |
| Rated Gross Power |
2,013 kW (2,700 HP) @ 1,800 rpm |
| Rated Net Power |
1,942 kW (2,604 HP) @ 1,800 rpm |
| Displacement |
90 L |
| Emission Standard |
Tier 2 |
| Fuel Tank Capacity |
10,400 L |
| Hydraulic System Capacity |
6,200 L |
| Max Digging Depth |
9,000 mm |
| Max Digging Radius (Ground Level) |
20,100 mm |
| Max Cutting Height |
20,600 mm |
| Max Dumping Height |
13,000 mm |
| Arm Digging Force |
1,250 kN |
| Max Traction Force |
2,100 kN |
| Travel Speed (Low/High) |
2.3 km/h |
| Swing Speed |
3.3 rpm |
| Gradeability |
35° (70%) |
| Ground Pressure |
230 kPa |
