USED KOBELCO SK250

USED KOBELCO SK250

$22,000.00 USD
$22,000.00 USD
Oferta Agotado

Core Specifications of KOBELCO SK250 (Standard Configuration) Kobelco

Category Specifications
Basic Information
Model KOBELCO SK250
Engine Model Hino J05ETB-KSSF (4-cylinder, water-cooled, turbocharged with intercooler, direct-injection diesel, Stage IV/Tier IV Final compliant)
Displacement 5.123 L (312.6 cu in)
Net Power 137 kW (184 HP) @ 2100 rpm (ISO 14396)
Operating Weight 24,900-25,400 kg (54,900-56,000 lbs, standard with dozer blade)
Standard Bucket Capacity 1.2 m³ (1.57 cu yd, heaped); 0.84 m³ (1.10 cu yd, struck)
Performance Parameters
Max Travel Speed 6.1 km/h (3.8 mph, high); 3.8 km/h (2.4 mph, low)
Max Digging Depth 6,700 mm (21.98 ft, standard arm)
Max Digging Height 9,700 mm (31.82 ft)
Max Dumping Height 6,900 mm (22.64 ft)
Max Digging Reach 10,200 mm (33.46 ft)
Swing Speed 10.8 rpm
Bucket Digging Force 170 kN (17,337 kgf, standard); 187 kN (19,072 kgf, power boost)
Arm Crowding Force 122 kN (12,440 kgf, standard); 130 kN (13,265 kgf, power boost)
Climbing Ability 35° (70%)
Drawbar Pull 244 kN (24,888 kgf, SAE standard)
Dimensions
Track Width 600 mm (23.62 in, standard); optional 800 mm (31.50 in)
Track Gauge 2,790 mm (9.15 ft)
Overall Length (bucket on ground) 9,650 mm (31.66 ft)
Overall Width 2,990 mm (9.81 ft)
Overall Height (top of cab) 3,080 mm (10.10 ft)
Min Ground Clearance 450 mm (17.72 in)
Rear Swing Radius 2,550 mm (8.37 ft)
Capacities
Fuel Tank 403 L (106.5 US gal)
Hydraulic System Fluid Capacity Approx. 273 L (72.1 US gal)
Hydraulic Tank Capacity 165 L (43.6 US gal)
Engine Oil Capacity 22 L (5.8 US gal)
Hydraulic System
Main Relief Pressure 34.3 MPa (4,974 psi, boom/arm/bucket/travel); 29.0 MPa (4,206 psi, swing); 37.8 MPa (5,482 psi, power boost)
Main Pump Flow 2 × 245 L/min (2 × 64.7 US gal/min); pilot pump flow: 21 L/min (5.55 US gal/min)
