USED KOBELCO SK70SR
USED KOBELCO SK70SR
Precio habitual
$11,000.00 USD
Precio habitual
Precio de oferta
$11,000.00 USD
Cantidad
No se pudo cargar la disponibilidad de retiro
Core Specifications of KOBELCO SK70SR (Standard Configuration)
| Category | Specifications |
|---|---|
| Basic Information | |
| Model | KOBELCO SK70SR |
| Engine Model | ISUZU CC - 4JG1 (4-cylinder, water - cooled, direct - injection diesel) |
| Displacement | 3.059 L (186.7 cu in) |
| Net Power | 40.5 kW (55 HP) @ 2100 rpm (ISO 9249/SAE J1349) |
| Max Torque | 187 N·m (137.9 lb·ft) @ 1800 rpm |
| Operating Weight | 7,200 kg (15,873 lbs) |
| Standard Bucket Capacity | 0.28 m³ (heaped); 0.22 m³ (struck) |
| Performance | |
| Max Travel Speed | 5.3 km/h (3.3 mph) (high); 2.8 km/h (1.7 mph) (low) |
| Max Digging Depth | 4,100 mm (13.45 ft) |
| Max Digging Height | 5,800 mm (19.03 ft) |
| Max Dumping Height | 4,300 mm (14.11 ft) |
| Swing Speed | 11.5 rpm |
| Bucket Digging Force | 52.7 kN (5,370 kgf) |
| Arm Crowding Force | 39.4 kN (4,020 kgf) |
| Climbing Ability | 35° |
| Dimensions | |
| Track Width | 450 mm (17.72 in) |
| Track Gauge | 1,870 mm (6.14 ft) |
| Overall Length (with bucket on ground) | 5,940 mm (19.49 ft) |
| Overall Width | 2,320 mm (7.61 ft) |
| Overall Height (top of cab) | 2,740 mm (9.0 ft) |
| Min Ground Clearance | 360 mm (14.17 in) |
| Rear Swing Radius | 1,290 mm (4.23 ft) |
| Capacities | |
| Fuel Tank | 120 L (31.7 gal) |
| Hydraulic System Fluid Capacity | Approx. 100 L (26.4 gal) |
| Hydraulic Tank Capacity | Approx. 72 L (19.0 gal) |
| Hydraulic System | |
| Main Relief Pressure | 29.4 MPa (4,264 psi) (boom, arm, bucket); 24.5 MPa (3,553 psi) (swing circuit) |
| Main Pump Flow | 2 × 66 L/min (2 × 17.44 gpm); pilot pump: 12 L/min (3.17 gpm) |
