| Official Model |
LONKING LG850H |
| Machine Type |
5‑Ton Heavy‑Duty Wheel Loader |
| Rated Load Capacity |
5000 kg |
| Standard Bucket Capacity |
3.0 m³ (Rock bucket optional: 2.7–3.3 m³) |
| Operating Weight |
17100 kg |
| Engine Model |
WEICHAI WP10H200E50 Diesel Engine (China National Stage V) |
| Rated Power |
147 kW (200 HP) @ 2000 rpm |
| Fuel Type |
Diesel |
| Fuel Tank Capacity |
240 L |
| Hydraulic System |
Load‑sensing High‑pressure Hydraulic System |
| Dump Clearance |
3120 mm |
| Reach at Full Dump |
1230 mm |
| Overall Length (with Bucket) |
8060 mm |
| Overall Width (Standard Tire) |
3000 mm |
| Overall Height (Top of Cab) |
3470 mm |
| Tire Specification |
23.5‑25 Heavy‑Duty Off‑road Tire |
| Travel Speed |
Forward: 0–38 km/h; Reverse: 0–24 km/h |
| Gradeability |
30° |
| Steering Mode |
Articulated Hydraulic Steering |
| Cab Configuration |
ROPS‑FOPS Enclosed Cab, Air‑Conditioning, Heating, Suspended Shock‑Absorbing Seat |
| Transmission System |
Planetary Power‑shift Transmission, 4‑Forward & 2‑Reverse Gears |
| Braking System |
Wet Multi‑disc Service Brakes, Hydraulic‑assisted |
| Main Applications |
Mining, quarrying, large‑scale construction, port bulk cargo handling, road construction, stockyard loading & unloading |
