USED SANY STG180C-8

USED SANY STG180C-8

$13,000.00 USD
$13,000.00 USD
Oferta Agotado
Parameter Value
Model SANY STG180C-8
Machine Type Motor Grader
Operating Weight 15800 kg
Standard Moldboard Length 3965 mm
Moldboard Height 610 mm
Max Cutting Depth 660 mm
Max Blade Lift Height 460 mm
Blade Rotation Angle 360°
Engine Model Cummins B6.7
Rated Power 132 kW @ 2200 rpm
Engine Displacement 6.7 L
Transmission Hydraulic Power Shift
Forward Gears 6
Reverse Gears 3
Max Forward Speed 39 km/h
Max Reverse Speed 25 km/h
Min Turning Radius 7.3 m
Front Wheel Lean Angle ±18°
Articulated Steering Angle ±25°
Gradeability 25%
Tire Size 14.00-24
Overall Length 8920 mm
Overall Width 2580 mm
Overall Height 3360 mm
Fuel Tank Capacity 290 L
Hydraulic Oil Tank Capacity 98 L
Working Hydraulic Pressure 20.5 MPa
Electrical System Voltage 24 V
