SANY

USED SANY STR130C-8

USED SANY STR130C-8

$10,000.00 USD
$10,000.00 USD
Oferta Agotado
Parameter Value
Model SANY STR130C-8
Machine Type Tandem Drum Vibratory Roller
Operating Weight 13000 kg
Front Drum Weight 6500 kg
Rear Drum Weight 6500 kg
Drum Width 2135 mm
Drum Diameter 1300 mm
Front Static Linear Load 298 N/cm
Rear Static Linear Load 298 N/cm
High Vibration Frequency 50 Hz
Low Vibration Frequency 43 Hz
High Amplitude 0.67 mm
Low Amplitude 0.305 mm
Max Centrifugal Force 130 kN
Min Centrifugal Force 80 kN
Engine Model Cummins QSB4.5-C160
Rated Power 119 kW @ 2200 rpm
Emission Standard China Stage IV
Working Travel Speed 0-7.5 km/h
Max Travel Speed 0-12.5 km/h
Gradeability (Vibratory) 30%
Gradeability (Non-Vibratory) 35%
Steering Mode Articulated Hydraulic Steering
Min Turning Radius 6.0 m
Overall Length 6250 mm
Overall Width 2360 mm
Overall Height 3150 mm
Fuel Tank Capacity 230 L
Water Tank Capacity 800 L
Hydraulic Oil Tank Capacity 120 L
Working Hydraulic Pressure 17.5 MPa
Electrical System Voltage 24 V
