SDLG

USED SDLG RS8260

USED SDLG RS8260

$24,000.00 USD
$24,000.00 USD
Oferta Agotado
Parameter Unit Value
Operating Weight kg 26000
Front Drum Weight kg 13000
Rear Axle Weight kg 13000
Drum Width mm 2150
Drum Diameter mm 1600
Engine Model - Weichai WP6G200E331
Rated Power kW/rpm 147/2000
Emission Standard - China Stage III
Vibration Frequency Hz 28/35 (high/low)
Nominal Amplitude mm 2.0/1.0 (high/low)
Exciting Force kN 420/295 (high/low)
Static Linear Pressure N/cm 605
Travel Speed km/h 0–11.5
Gradeability % 30
Steering Angle ° ±35
Oscillation Angle ° ±12
Min Turning Radius mm 6674
Wheelbase mm 3518
Min Ground Clearance mm 420
Overall Length mm 6868
Overall Width mm 2400
Overall Height mm 3367
Fuel Tank Capacity L 270
Hydraulic Tank Capacity L 200
Ver todos los detalles
