| Model |
SEM 656D (5-ton Long-wheelbase Wheel Loader) |
| Operating Weight |
17,200 kg (37,920 lb) |
| Rated Load |
5,000 kg (5 ton) |
| Bucket Capacity (Std) |
2.7–4.5 m³ (3.0 m³ std) |
| Engine Model |
Weichai WP10G220E343 (6-cyl turbo diesel, 9.7L) |
| Rated Power |
162 kW / 220 HP @ 2,000 rpm |
| Emission |
Euro 3 / Tier 3 / 国三 |
| Max Breakout Force |
178 kN |
| Max Traction Force |
168 kN |
| Travel Speed (Fwd 1–4) |
7.9 / 15.3 / 23.5 / 39 km/h |
| Hydraulic Pressure |
170 bar (17 MPa) |
| Lift Time |
5.06 s |
| Total Cycle Time |
9.4 s |
| Max Dump Height |
3,111 mm |
| Wheelbase |
3,300 mm (100mm longer than 655D) |
| Turning Radius (Outer) |
6,837 mm |
| Tire Size |
23.5–25 (PR16) |
| Fuel Tank |
252 L |
| Hydraulic Tank |
165 L |
| Key Features |
5t long-wheelbase heavy-duty, 220HP Weichai, single-load-sensing hydraulics, Cat cooling, reinforced frame, high stability, long-distance efficient |
