TCM

USED TCM FORKLIFT FD35

$6,000.00 USD

Oferta Agotado

Item	Specification
Model	TCM FD35
Rated Load Capacity	3500 kg
Load Center Distance	500 mm
Overall Length (Without Fork)	2720 mm
Overall Width	1225 mm
Overall Height (Mast Lowered)	2160 mm
Max Lifting Height	3000 mm
Free Lift Height	150 mm
Fork Size	1070×122×45 mm
Front Wheel Track	970 mm
Rear Wheel Track	980 mm
Wheelbase	1525 mm
Min Turning Radius	2350 mm
Min Ground Clearance	135 mm
Max Travel Speed (Full Load)	18 km/h
Max Climbing Gradient (Full Load)	20%
Mast Tilt Angle (Forward/Backward)	6° / 12°
Front Tire Specification	6.50-10
Rear Tire Specification	5.00-8
Engine Model	ISUZU C240
Engine Type	4-cylinder Water-cooled Diesel Engine
Rated Power	37 kW / 50 HP
Rated Speed	2600 rpm
Fuel Tank Capacity	60 L
Hydraulic Oil Tank Capacity	45 L
Transmission Type	Mechanical / Hydraulic Automatic
Service Weight	4850 kg
Brake Type	Foot Hydraulic Brake + Hand Parking Brake
Operating Mode	Seated Driving
