| Model |
JCB 4CX (Standard/Pro Version) |
| Machine Type |
Backhoe Loader |
| Engine Model |
JCB EcoMax 4.8 L (Pro)/4.4 L (Eco) |
| Rated Power |
81 kW (109 hp) @ 2200 rpm (Pro)/74.2 kW (100 hp) (Eco) |
| Max. Torque |
516 N.m @ 1300 rpm |
| Operating Weight |
8178-8578 kg (Standard)/8580 kg (Pro) |
| Loader Bucket Capacity |
1.1 m³ (1.0-1.2 m³ Optional) |
| Backhoe Bucket Capacity |
0.3 m³ (Optional) |
| Max. Digging Depth (Standard Stick) |
4.32 m |
| Max. Digging Depth (Extendable Stick) |
6.55 m |
| Max. Reach From Swivel |
5.4 m (Standard)/6.74 m (Extendable) |
| Max. Dumping Height (Backhoe) |
2.69 m |
| Max. Breakout Force (Loader) |
61.06 kN |
| Max. Traction Force |
65 kN |
| Transmission |
6 - speed Autoshift with TorqueLock (Pro)/4 - speed Powershift (Eco) |
| Max. Travel Speed (Forward/Reverse) |
38.1-40 km/h |
| Turning Radius (4WD) |
6.0 m |
| Fuel Tank Capacity |
160 L |
| Hydraulic System Fluid Capacity |
120 L |
| Drive Type |
4WD |
| Steering Modes |
2 - wheel/4 - wheel/Crab |
