| Model |
CAT M315GC Wheeled Excavator |
| Operating Weight |
14,300 kg (standard configuration with cab, operator, full fuel tank, 4.4 m boom, 2.2 m stick, 0.65 m³ bucket, and standard tires)Cat
|
| Engine Model |
CAT C4.4 (4-cylinder, 4-stroke, turbocharged, water-cooled diesel engine)Cat
|
| Displacement |
4.4 LCat
|
| Rated Net Power |
104 kW (141 hp) @ 2,200 rpm (ISO 9249) |
| Rated Gross Power |
110 kW (148 hp) @ 2,200 rpm (ISO 14396)Cat
|
| Bucket Capacity |
0.65 m³ (standard) |
| Max Travel Speed |
37 km/h (23 mph)Cat
|
| Swing Speed |
11.5 rpm |
| Max Digging Depth |
4,624 mm (4.4 m boom, 2.2 m stick) |
| Max Digging Height |
8,392 mm |
| Max Digging Radius |
7,739 mm |
| Hydraulic System |
Open-Center Load-Sensing Hydraulic System (Single Piston Pump)Cat
|
| Pump Flow |
245 L/min @ 2,200 rpmCat
|
| Max Operating Pressure (Implement) |
350 bar (5,076 psi)Cat
|
| Max Operating Pressure (Travel) |
350 bar (5,076 psi)Cat
|
| Max Operating Pressure (Swing) |
259 bar (3,756 psi)Cat
|
| Max Bucket Digging Force |
86 kN (ISO 10567) |
| Max Stick Digging Force |
62 kN (ISO 10567) |
| Max Traction Force |
71 kN |
| Emission Standard |
U.S. EPA Tier 3 / EU Stage IIIA (equivalent to Brazil MAR-1)Cat
|
| Fuel Tank Capacity |
250 L |
| Hydraulic Tank Capacity |
98 L |
| Tail Swing Radius |
2,190 mm |
