NEW SANY SY335H

NEW SANY SY335H

$78,000.00 USD
$78,000.00 USD
Sale Sold out

Here are the parameters of the NEW SANY SY335H in a tabular format in English:

Parameter Description
Model SY335H
Type Medium Excavator
Operating Weight 32,500 kg
Bucket Capacity 1.85 m³
Engine Model Isuzu GH-6HK1 (or 6HK1)
Rated Power 212 kW / 2000 rpm
Maximum Torque 1080 N·m / 1500 rpm
Displacement 7.79 L
Emission Standard China IV (equivalent to EU Stage IV)
Fuel Tank Capacity 540 L (some sources indicate 530 L)
Hydraulic Oil Tank Capacity 380 L (some sources indicate 420 L)
Engine Oil Capacity 35 L (some sources indicate 2×4.0 L)
Coolant Capacity 35 L
Overall Length (Transport) 10,667 mm
Overall Width 3,190 mm
Overall Height (Transport) 3,470 mm
Upper Width 3,175 mm
Height (Cab Top) 3,280 mm
Standard Track Shoe Width 600 mm
Track Gauge 2,590 mm
Minimum Ground Clearance 550 mm
Tail Swing Radius 3,315 mm
Ground Contact Length of Track 4,134 mm
Track Length 5,040 mm
Travel Speed (High/Low) 5.4 km/h / 3.2 km/h
Swing Speed 9.0 rpm (some sources indicate 9.5 rpm)
Gradeability 70% (35°)
Ground Pressure 60.3 kPa
Bucket Digging Force 204 kN
Arm Digging Force 153 kN
Maximum Digging Height 10,497 mm
Maximum Dumping Height 7,359 mm
Maximum Digging Depth 6,815 mm
Maximum Digging Radius 10,870 mm
Minimum Swing Radius (Front) 4,000 mm
Minimum Swing Radius (Height) 8,405 mm
