SHANTUI
NEW SHANTUI SD17-G
NEW SHANTUI SD17-G
Regular price
$52,000.00 USD
Regular price
Sale price
$52,000.00 USD
Quantity
Couldn't load pickup availability
Here are the core parameters of the NEW SHANTUI SD17-G in a tabular format in English:
| Parameter | Description |
|---|---|
| Model | SD17-G |
| Type | Bulldozer |
| Engine Model | WP9H |
| Rated Power/Rated Speed | 140 kW / 1900 rpm (with an optional 152 kW / 1900 rpm version) |
| Emission Standard | National Non-Road Stage IV (China IV) |
| Operating Weight | 17,120 kg (with tow hitch, varies by configuration: 17,420 kg with 610mm track shoes and tow hitch, 17,620 kg with tow hitch for coal version, 19,360 kg for Super Wetland Edition, 19,790 kg for Sanitation Version) |
| Ground Pressure | 54 kPa (standard, 49 kPa for coal version with specific track shoes, 27 kPa for Super Wetland Edition and Sanitation Version, 35 kPa for Desert Version) |
| Minimum Turning Radius | 4,400 mm (Super Wetland Edition and Sanitation Version), 4,467 mm (Coal Version), 2,509 mm (specific configuration, possibly XL version) |
| Overall Dimensions (L×W×H) | 5,450 mm × 3,452 mm × 3,200 mm (XL version), 5,950 mm × 3,905 mm × 3,200 mm (Coal Version), 5,500 mm × 4,230 mm × 3,240 mm (Super Wetland Edition and Sanitation Version), 5,500 mm × 4,230 mm × 3,622 mm (Desert Version) |
| Forward Speeds | F1: 0-3.5 km/h, F2: 0-6.2 km/h, F3: 0-10.6 km/h |
| Reverse Speeds | R1: 0-4.5 km/h, R2: 0-8.0 km/h, R3: 0-13.1 km/h |
| Chassis System | |
| Track Center Distance | 1,880 mm (standard, XL, and Coal versions), 2,300 mm (Super Wetland Edition, Sanitation Version, and Desert Version) |
| Track Shoe Width | 510 mm (standard, with options for 560 mm and 610 mm), 610 mm (Coal Version), 1,100 mm / 950 mm (Super Wetland Edition and Sanitation Version, with an optional 660 mm), 810 mm (Desert Version) |
| Ground Contact Length | 2,635 mm (standard and Coal versions, with an optional 2,675 mm), 2,935 mm (Super Wetland Edition, Sanitation Version, and Desert Version) |
| Fuel Tank Capacity | 345 L |
| Working Hydraulic Oil Tank Capacity | 75 L (standard, Super Wetland Edition, Sanitation Version, and Desert Version), 70 L (Coal Version) |
| Blade Type | Straight-tilt blade (standard and XL versions), coal pusher (Coal Version), sanitation shovel (Sanitation Version), straight-tilting shovel (half U shovel, Desert Version) |
| Blade Cutting Depth | 540 mm (standard, XL, and Coal versions), 485 mm (Super Wetland Edition and Sanitation Version) |
| Scarifier Type | Three-tooth (standard, XL, Super Wetland Edition, and Coal versions) |
| Soil Loosening Depth | 460 mm (standard and Coal versions) |
