KOBELCO
Used Kobelco SK230 Excavator for Sale
Used Kobelco SK230 Excavator for Sale
Regular price
$22,000.00 USD
Regular price
Sale price
$22,000.00 USD
Quantity
Couldn't load pickup availability
| Item | Specification |
|---|---|
| Model | KOBELCO SK230 Hydraulic Crawler Excavator |
| Operating Weight (Std Cab + 600mm Track) | 23600 kg |
| Standard Heaped Bucket Capacity (ISO) | 0.90 m³ (Optional: 0.75–1.10 m³) |
| Overall Transport Length | 9850 mm |
| Overall Transport Width | 2990 mm |
| Overall Transport Height (Cab Top) | 3120 mm |
| Standard Track Shoe Width | 600 mm |
| Track Gauge | 2390 mm |
| Track Length on Ground | 3450 mm |
| Ground Clearance | 480 mm |
| Rear Swing Radius | 2820 mm |
| Engine Model | MITSUBISHI 6D34-TLU2F |
| Engine Type | Water-cooled, 4-stroke, 6-cylinder, turbocharged, intercooled diesel |
| Rated Net Power | 125 kW @ 2100 rpm |
| Engine Displacement | 5.98 L |
| Max Engine Torque | 580 N·m @ 1600 rpm |
| Fuel Tank Capacity | 350 L |
| Hydraulic Tank / Full System Volume | 150 L / 260 L |
| Main Hydraulic Relief Pressure (Normal/Boost) | 34.3 MPa / 37.8 MPa |
| Total Main Pump Flow | 2×230 L/min + 20 L/min |
| Max Digging Reach (Ground Level) | 9800 mm |
| Max Total Digging Reach | 10100 mm |
| Max Digging Depth | 6870 mm |
| Max Vertical Wall Digging Depth | 6050 mm |
| Max Digging Height | 9850 mm |
| Max Dumping Height | 7530 mm |
| Bucket Digging Force (ISO/Normal) | 165 kN (182 kN with Power Boost) |
| Arm Digging Force (ISO/Normal) | 113 kN (125 kN with Power Boost) |
| Drawbar Pull Force | 245 kN |
| Swing Speed | 12.0 rpm |
| Travel Speed (Low/High) | 3.1 km/h / 5.5 km/h |
| Gradeability | 35° (70%) |
| Ground Contact Pressure | 47.5 kPa |
| Standard Boom Length | 5700 mm |
| Standard Stick Length | 3000 mm |
