| Model |
KOBELCO SK30SR-6 Compact Zero Tail Hydraulic Mini Excavator |
| Operating Weight(Cab Version) |
3455 kg |
| Standard Heaped Bucket Capacity |
0.085 m³ (Optional:0.07~0.10 m³) |
| Overall Transport Length |
4390 mm |
| Overall Transport Width |
1550 mm |
| Overall Transport Height(Cab Top) |
2510 mm |
| Standard Rubber Track Shoe Width |
300 mm |
| Track Gauge |
1300 mm |
| Track Length on Ground |
1720 mm |
| Ground Clearance |
285 mm |
| Minimum Tail Swing Radius |
790 mm(Zero Tail Swing Design) |
| Engine Model |
YANMAR 3TNV82A-B 3-Cylinder Diesel Engine |
| Engine Type |
Water-cooled,4-stroke,naturally aspirated direct injection diesel |
| Rated Net Power |
18.1 kW @2400 rpm(ISO14396)Kobelco Construction Machinery
|
| Engine Displacement |
1.331 L |
| Max Engine Torque |
79.4 N·m @1350 rpm |
| Fuel Tank Capacity |
42.0 L |
| Hydraulic Oil Tank Capacity |
20.4 L(Tank),Total System 44.8 L |
| Main Hydraulic Working Pressure |
23.0 MPa |
| Max Digging Reach(Ground Level) |
5240 mm |
| Max Digging Depth |
2830 mm |
| Max Vertical Wall Digging Depth |
2580 mm |
| Max Digging Height |
4620 mm |
| Max Dumping Height |
3390 mm |
| Bucket Digging Force(ISO) |
27.7 kN |
| Arm Digging Force(ISO) |
19.1 kN |
| Swing Speed |
8.4 rpm |
| Travel Speed(Low/High) |
2.5 km/h / 4.4 km/h |
| Gradeability |
30°(58%) |
| Average Ground Pressure |
32.5 kPa |
| Standard Boom Length |
2210 mm |
| Standard Stick Length |
1320 mm |
| Standard Dozer Blade Width |
1550 mm |
