| Model |
KOMATSU D275A-5R |
| Engine |
Model: SAA6D140E-5 (6-cylinder, turbocharged & aftercooled diesel)
Gross Power: 452 hp (337 kW) @ 2000 rpm
Net Power: 449 hp (335 kW) @ 2000 rpm
Displacement: 930 cu in (15.24 L)
Bore × Stroke: 140 mm × 165 mm |
| Transmission |
Type: Komatsu TORQFLOW (torque converter)
Gears: 4 forward, 4 reverse
Max Forward Speed: 7.0 mph (11.2 kph)
Max Reverse Speed: 9.3 mph (14.9 kph) |
| Operating Weight |
112,100 lbs (50,850 kg) (ROPS cab, SU blade, full fuel, operator, standard equipment) |
| Blade (Semi-Universal - SU) |
Capacity: 17.9 yd³ (13.7 m³)
Full-U Blade Capacity: 21.7 yd³ (16.6 m³)
Width: 13.8 ft (4.2 m)
Height: 77.6 in (1.97 m) |
| Dimensions |
Length (with blade): 30.5 ft (9.29 m)
Width (over tracks): 14.1 ft (4.3 m)
Height (top of cab): 13.1 ft (3.99 m)
Ground Clearance: 1.8 ft (0.55 m)
Track Gauge: 9.6 ft (2.935 m) |
| Undercarriage |
Track Rollers per Side: 8
Carrier Rollers per Side: 2
Standard Shoe Size: 24 in (610 mm)
Ground Pressure: 12.5 psi (86.2 kPa) |
| Capacities |
Fuel Tank: 222 gal (840 L)
Hydraulic System: 35.2 gal (133 L)
Engine Oil: 13.5 gal (51 L)
Coolant: 36 gal (136 L) |
