Here are the parameters of the NEW SHANTUI SG21-G in a tabular format in English:
Parameter
Description
Model
SG21-G
Type
Motor Grader
Engine Model
WP7
Rated Power/Rated Speed
162 kW / 2200 rpm
Emission Standard
China IV (equivalent to EU Stage II)
Operating Weight
17,000 kg
Blade Dimensions (L×H)
4,270 mm × 620 mm
Blade Cutting Angle Adjustment Range
22°-73°
Maximum Lift Height of the Blade
480 mm
Maximum Cutting Depth of the Blade
970 mm
Minimum Turning Radius
7,500 mm
Maximum Traction (f=0.8)
93.3 kN
Maximum Speed Forward/Backward
0-40 km/h / 0-25 km/h
Gradeability
20°
Overall Dimensions (L×W×H)
9,700 mm × 2,600 mm × 3,358 mm
Rear Axle Ground Clearance
375 mm
Fuel Tank Capacity
330 L
Transmission
Hydraulic transmission, electronically controlled for smooth gear shifting
Steering System
Electric hand and foot dual throttle control for one-button constant speed
Cab Features
Four-column six-sided anti-falling object and anti-rollover cab with a wide field of vision, multi-degree-of-freedom adjustable console, and large-power heating and cooling air conditioning
Additional Features
Load-sensitive technology, blade obstacle avoidance function, and configurable with various attachments such as front bulldozer plates, rear ripper, middle loosening rake, and front loosening rake
