| Model |
Cat 326D2 |
| Engine |
Cat C7.1 ACERT (turbocharged, aftercooled diesel, Tier 2/EU Stage II compliant) |
| Displacement |
7.1 L (433 in³) |
| Rated Power |
147 kW (197 hp) @ 1800 rpm (net, ISO 9249) |
| Cylinder Bore × Stroke |
105 mm × 135 mm |
| Operating Weight |
25765–26075 kg (26075 kg for long undercarriage) |
| Bucket Capacity |
1.2–1.4 m³ (standard 1.33 m³) |
| Max. Digging Depth |
6850 mm (with 5.9 m boom & 2.95 m stick) |
| Max. Reach Along Ground |
10150 mm |
| Max. Loading Height |
7200 mm |
| Swing Speed |
9.6 rpm |
| Travel Speed |
3.5/5.8 km/h (two - speed) |
| Drawbar Pull |
227 kN |
| Bucket Digging Force |
166 kN |
| Stick Digging Force |
120 kN |
| Hydraulic System Pressure |
Main: 35000 kPa; Travel: 35000 kPa; Swing: 24500 kPa; Pilot: 3900 kPa |
| Hydraulic Flow (Main Pumps) |
2×233 L/min (total 466 L/min) |
| Fuel Tank Capacity |
520 L |
| Hydraulic System Capacity (Including Tank) |
285 L |
| Engine Oil Capacity |
22 L |
