CATERPILLAR

USED CAT 430F

USED CAT 430F

$24,000.00 USD
$24,000.00 USD
أُوكَازيُون نفذ

Cat 430F Core Specifications (English)

Category Parameter Value
Weight Nominal Operating Weight 7,125 kg / 15,708 lb
Maximum Operating Weight 11,000 kg / 24,251 lb
Engine Model Cat C4.4 ACERT DIT
Net Power (SAE J1349) 80 kW (107 hp) @ 2,200 rpm
Gross Power (SAE J1995) 87 kW (117 hp)
Displacement 4.4 L (268 in³)
Max Torque 489 N·m (359 lb-ft) @ 1,400 rpm
Emission Standard U.S. EPA Tier 4 Interim / EU Stage IIIB
Loader Performance Bucket Capacity 0.96 m³ (1.25 yd³)
Bucket Breakout Force 49.8 kN (11,195 lb)
Lift Capacity (Full Height) 3,282 kg (7,237 lb)
Max Dump Height 2.746 m (9 ft)
Backhoe Performance Standard Dig Depth 4.698 m (15.4 ft)
Extended Dig Depth (E-stick) 5.8 m (19 ft)
Backhoe Breakout Force 71.86 kN (16,155 lb)
Max Horizontal Reach 6.043 m (19.8 ft)
Dimensions Transport Length 7.282 m (23.9 ft)
Transport Width 2.322 m (7.6 ft)
Transport Height 3.577 m (11.7 ft)
Wheelbase 2.2 m (7.22 ft)
Key Auxiliary Specs Travel Speed 40 km/h (25 mph)
Hydraulic Pump Flow 163 L/min (43.1 gpm)
Fuel Tank Capacity 170 L (44.9 gal)
Standard Tires Front: 12.5/80-18 (12 ply) F-3; Re
