USED VOLVO EC460DL

USED VOLVO EC460DL

$42,000.00 USD
$42,000.00 USD
أُوكَازيُون نفذ

Here are the core parameters of the VOLVO EC460DL excavator in a tabular format in English:

Parameter Description
Model VOLVO EC460DL
Type Large-sized hydraulic excavator
Tonnage Approximately 46 - 53 tons
Engine Model VOLVO D13C460S EUV (or other D13 series engines, depending on the specific variant)
Rated Power 265 - 339 kW (at 1700 - 1800 rpm)
Displacement 12.8 - 13 liters
Number of Cylinders 6
Bucket Capacity 1.77 - 3.8 cubic meters
Operating Weight 47,300 - 53,100 kg
Swing Speed Approximately 8.5 - 10 rpm (depending on the specific variant)
Travel Speed (High/Low) 3.1 - 5.5 km/h (depending on the specific variant)
Gradeability 70% (or 35°, depending on the measurement method)
Ground Pressure Varies depending on the track shoe width and operating weight
Bucket Digging Force (SAE J1179) 230 - 251 kN (normal mode) / 244.2 - 276.5 kN (power boost mode)
Arm Digging Force (SAE J1179) 160 - 174 kN (normal mode) / 195.1 - 213.8 kN (power boost mode)
Maximum Traction Force Not specified (but typically high for this class)
Fuel Tank Capacity 685 liters
Hydraulic Oil Tank Capacity 270 liters
Engine Oil Replacement Volume 42 liters
Coolant Capacity 60 liters
Overall Dimensions (Length×Width×Height) Varies depending on the configuration, but typically around 11.63 × 3.34 × 3.257 meters
Maximum Digging Radius 10,930 - 13,260 mm
Maximum Digging Depth 7,700 - 9,170 mm
Maximum Digging Height 10,330 - 10,970 mm
Maximum Unloading Height 6,970 - 7,650 mm
Maximum Vertical Digging Depth 5,990 - 6,840 mm
