| Engine Model |
3176C DITA ATAAC VHP |
6-cylinder, 10.3 L (629 cu in) displacement |
| Power |
Max Power (Gears 3-8) |
185 hp (138 kW) @ 2000 rpm |
|
Net Power (Gears 1-2) |
165 hp (123 kW) @ 2000 rpm |
| Transmission |
Type |
Direct drive, power shift |
|
Forward/Reverse Gears |
8 forward / 6 reverse |
|
Max Speed (Forward/Reverse) |
27.4 mph (44 km/h)/21.6 mph (34.7 km/h) |
| Operating Weight |
Standard (Front/Rear/Total) |
9,123 lb (4,138 kg)/23,234 lb (10,539 kg)/32,357 lb (14,678 kg) |
| Hydraulic System |
Fluid Capacity |
20.8 gal (80 L) |
|
Pump Type/Flow Pressure |
Axial piston / 206 L/min, 24,150 kPa |
| Front Axle |
Wheel Lean/Oscillation |
18 degrees/32 degrees total |
| Blade |
Width |
156 in (3974 mm) |
|
Max Cutting Depth |
28.1 in (715 mm) |
