| Engine |
Model |
Mitsubishi 4M40TL (4‑cylinder, 2.83 L / 172.7 cu in displacement) |
|
Gross Power |
58 hp (43 kW) @ 2200 rpm |
|
Net Power (SAE J1349/ISO 9249) |
55.6 hp (41.5 kW) @ 2200 rpm |
| Operating Weight |
Standard (cab, steel tracks, 0.31 m³ bucket, operator, full fuel) |
15,858 lb (7,193 kg) |
|
Canopy config |
15,598 lb (7,075 kg) (approx.) |
| Digging Performance |
Max Dig Depth |
13 ft 3 in (4,040 mm) (approx.) |
|
Max Reach (ground level) |
20 ft 8 in (6,300 mm) (approx.) |
|
Bucket Digging Force |
11,023 lbf (49.0 kN) |
|
Stick Digging Force |
7,947 lbf (35.4 kN) (approx.) |
| Travel |
Speed (Low/High) |
1.9 mph (3.1 km/h)/3.1 mph (5.0 km/h) |
|
Gradeability |
35° (70%) |
| Hydraulics |
System Pressure |
4,641 psi (32,000 kPa) |
|
Swing Speed |
10 rpm |
| Fuel Capacity |
35.7 gal (135 L) |
