| Engine |
Model |
Cat C2.4 Turbo (4-cylinder, 2.4 L / 146.5 cu in displacement) |
|
Gross Power (ISO 14396) |
53.1 hp (39.6 kW) @ 2200 rpm |
|
Net Power (ISO 9249/SAE J1349) |
50.6 hp (37.7 kW) @ 2200 rpm |
| Operating Weight |
Standard (cab, steel tracks with rubber pads, 0.33 m³ bucket, operator, full fuel, auxiliary lines) |
16,028 lb (7,270 kg) |
| Digging Performance |
Max Dig Depth |
13 ft 4 in (4,070 mm)Cat
|
|
Max Dig Reach (ground level) |
20 ft 8 in (6,300 mm)Cat
|
|
Bucket Digging Force |
11,378 lbf (50.6 kN) (approx.) |
|
Stick Digging Force |
7,275 lbf (32.4 kN) (approx.) |
| Travel |
Speed (Low/High) |
1.7 mph (2.8 km/h) / 3.0 mph (4.8 km/h) (approx.) |
|
Max Traction Force |
10,900 lbf (48.5 kN) (approx.) |
|
Gradeability |
30° (approx.) |
| Hydraulics |
System Pressure |
4,060 psi (28,000 kPa)Cat
|
|
Swing Speed |
10.2 rpm |
| Fuel Capacity |
35.7 gal (135 L) |
