USED HYUNDAI R60-7

USED HYUNDAI R60-7

$12,000.00 USD
$12,000.00 USD
Obral Habis
Category Parameters
Basic Info Model: Hyundai R60-7

Type: Hydraulic Crawler Mini Excavator

Operating Weight: 12,897 lb (5,850 kg)

Standard Bucket Capacity: 0.21 m³ (0.27 yd³); Range: 0.06-0.21 m³ (0.08-0.27 yd³)
Engine Model: Yanmar 4TNV94L

Type: 4-cylinder, water - cooled diesel

Displacement: 2.19 L (133.6 cu in)

Net Power: 53.6 hp (40 kW) @ 2,200 rpm

Max Torque: 189 N•m (139 lbf - ft) @ 1,600 rpm
Hydraulics System Relief Pressure: 3,626 psi (25 MPa)

Main Pump Flow: 26.4 gal/min (100 L/min)

Hydraulic Fluid Capacity: 18.5 gal (70 L)
Performance Max Travel Speed (High/Low): 2.49 mph/1.37 mph (4.0/2.2 km/h)

Swing Speed: 9.6 rpm

Bucket Digging Force: 37.7 kN (8,475 lbf)

Stick Digging Force: 28.4 kN (6,385 lbf)

Max Digging Depth: 12.53 ft (3.82 m)

Max Digging Reach (Ground Level): 20.18 ft (6.15 m)

Max Loading Height: 13.29 ft (4.05 m)

Gradeability: 70% (35°)
Capacities Fuel Tank: 31.7 gal (120 L)

Engine Oil: 3.96 gal (15 L)

Cooling System: 4.4 gal (16.6 L)
Dimensions Transport Length×Width×Height: 19.36 ft×6.30 ft×8.37 ft (5,900×1,920×2,550 mm)

Track Gauge: 4.92 ft (1,500 mm)

Track Shoe Width: 15.75 in (400 mm)

Tail Swing Radius: 5.41 ft (1,650 mm)

Min Ground Clearance: 1.25 ft (380 mm)
Electrical System Voltage: 12 V

Alternator Output: 40 A
