Gross Power: 221 hp (165 kW) @ 2100 rpm
Net Power: 218 hp (163 kW) @ 2100 rpm
Displacement: 6.69 L (408 cu in)
Bore × Stroke: 107 mm × 124 mm
Max Torque: 694 lb-ft (96 kg/m) @ 1450 rpmKomatsuTransmissionType: Full power shift with torque converter (lock-up, integral free-wheeling stator)
Gears: 8 forward, 4 reverse
Max Forward Speed: 27.5 mph (44.3 kph)
Max Reverse Speed: 25.1 mph (40.3 kph)KomatsuOperating Weight38,250 lbs (17,350 kg) (standard configuration, ROPS cab, operator, full fuel tank)KomatsuMoldboardLength: 14 ft (4.0 m)
Range (Left/Right): 32.3 in (820 mm) each
Blade Angle: 30° (max)KomatsuDimensionsLength (overall): 35.1 ft (10.7 m)
Width (over tires): 9.5 ft (2.9 m)
Height (top of cab): 12.1 ft (3.68 m)
Wheelbase: 20.3 ft (6.19 m)
Ground Clearance: 1.5 ft (0.46 m)CapacitiesFuel Tank: 100.6 gal (381 L)
Hydraulic System: 34.3 gal (130 L)
Engine Oil: 8.5 gal (32 L)
Coolant: 15.9 gal (60 L)
