| Basic Information |
|
| Model |
Komatsu PC130-8 |
| Engine Model |
Komatsu SAA4D95LE-5 (4-cylinder, water-cooled, turbocharged diesel with common rail fuel injection)コマツ
|
| Displacement |
3.92 L (239.3 cu in) |
| Gross Power |
72.1 kW (96.6 HP) @ 2200 rpm (SAE J1995)コマツ
|
| Net Power |
68.4 kW (91.7 HP) @ 2200 rpm (ISO 9249/SAE J1349)コマツ
|
| Operating Weight |
12,380-12,740 kg (27,300-28,100 lbs)コマツ
|
| Standard Bucket Capacity |
0.53 m³ (0.18-0.60 m³ optional)コマツ
|
| Performance |
|
| Max Travel Speed |
5.5 km/h (high); 2.9 km/h (low) |
| Max Bucket Digging Force (ISO) |
93.4 kN (9,520 kgf) |
| Max Arm Digging Force (ISO) |
67.5 kN (6,880 kgf) |
| Swing Speed |
11.5 rpm |
| Ground Pressure |
41.2 kPa (5.97 psi) |
| Dimensions |
|
| Transport Length |
7,590 mm |
| Transport Width |
2,490 mm |
| Transport Height |
2,850 mm |
| Max Digging Depth |
5,520 mm |
| Max Dumping Height |
7,170 mm |
| Max Digging Radius |
8,290 mm |
| Capacities |
|
| Fuel Tank |
200 L (52.8 gal) |
| Hydraulic System Fluid Capacity |
69 L (18.2 gal) |
| Engine Oil Capacity |
17 L (4.5 gal) |
| Coolant Capacity |
18.2 L (4.8 gal) |
| Hydraulic System |
|
| Main Relief Pressure |
34.3 MPa (4,975 psi) |
| Main Pump Flow |
226 L/min (59.7 gpm) |
