| Engine |
Model |
Cat C2.6 DL Turbo (4-cylinder, 2.6 L / 160 cu in displacement) |
|
Gross Power |
57.6 hp (43.0 kW) @ 2000 rpm |
|
Net Power (ISO 9249/SAE J1349) |
55.6 hp (41.5 kW) @ 2200 rpm |
| Operating Weight |
Standard (cab, steel tracks, 0.22 m³ bucket, operator, full fuel) |
12,776 lb (5,795 kg) |
|
Canopy config |
12,566 lb (5,700 kg) (approx.) |
| Digging Performance |
Max Dig Depth |
12 ft 6 in (3,800 mm) |
|
Max Dig Reach (ground level) |
20 ft 2 in (6,140 mm) |
|
Bucket Digging Force |
8,992 lbf (40.0 kN) |
|
Stick Digging Force |
5,845 lbf (26.0 kN) |
| Travel |
Speed (Low/High) |
1.7 mph (2.8 km/h) / 3.0 mph (4.8 km/h) |
|
Max Traction Force |
10,836 lbf (48.2 kN) |
|
Gradeability |
30° (approx.) |
| Hydraulics |
System Pressure |
3,553 psi (24,500 kPa) (approx.) |
|
Swing Speed |
10.3 rpm |
| Fuel Capacity |
35.7 gal (135 L) |
|
