| Model |
Hitachi EX1900‑6 (Loading Shovel / Backhoe) |
| Operating Weight |
Loading Shovel: 191,000 kg / Backhoe: 192,000 kg
|
| Standard Bucket Capacity (ISO Heaped) |
Loading Shovel: 11.0–12.0 m³ / Backhoe: 4.4–12.0 m³
|
| Overall Dimensions (L×W×H) |
17,800 × 6,660 × 6,990 mm |
| Track Shoe Width |
800 mm |
| Track Gauge |
5,400 mm |
| Min. Ground Clearance |
795 mm |
| Track Length on Ground |
5,780 mm |
| Engine Model |
Cummins QSKTA38‑CE (4‑stroke, water‑cooled, turbocharged)
|
| Rated Power |
810 kW (1,102 HP) @ 1,800 rpm
|
| Displacement |
37.8 L |
| Emission Standard |
Tier 2 |
| Fuel Tank Capacity |
3,085 L |
| Hydraulic System Capacity |
2,200 L |
| Max Digging Depth |
5,920 mm |
| Max Digging Radius (Ground Level) |
13,430 mm |
| Max Cutting Height |
14,610 mm |
| Max Dumping Height |
10,440 mm |
| Bucket Digging Force |
754 kN |
| Arm Digging Force |
720 kN |
| Max Traction Force |
1,020 kN |
| Travel Speed (Low/High) |
2.0 / 3.0 km/h |
| Swing Speed |
4.7 rpm |
| Gradeability |
35° (70%) |
| Ground Pressure |
228 kPa |
