Used Hitachi EX200-2 Excavator for Sale
Used Hitachi EX200-2 Excavator for Sale
Couldn't load pickup availability
Used Hitachi EX200-2 Excavator for Sale
This Hitachi EX200-2 Excavator is available from CN Used Machinery for international buyers looking for reliable construction equipment. It is suitable for contractors, equipment dealers, rental companies, and project buyers who need practical performance and export support.
Key Specifications
| Brand | Hitachi |
| Model | EX200-2 |
| Machine Type | Excavator |
| Condition | Used |
| Parameter | Details |
| Engine | Model: Isuzu 6BD1T (6-cylinder, water-cooled, turbocharged diesel) Rated Net Power: 99 kW (133 hp) @ 2050 rpm (DIN 6271); 98.4 kW (132 hp) @ 2050 rpm (SAE J1349) Displacement: 5.7 L (348 cu in) Bore×Stroke: 102 mm×118 mm Max Torque: 461 N·m @ 1600 rpm Aspiration: Turbocharged |
| Hydraulic System | Type: Open-center, two variable-displacement axial-piston pumps Main Pump Flow: 2×105 L/min, total 210 L/min (55.5 gal/min) Relief Valve Pressure: 34.3 MPa (4980 psi) Hydraulic Fluid Capacity: 180 L (47.6 US gal) |
| Operating Weight | 18,500 kg (40,785 lbs) (standard configuration with bucket and boom) |
| Bucket (Standard) | Capacity: 0.8 m³ (1.05 yd³) (heaped); Optional: 0.51-1.2 m³ Max Digging Depth: 5980 mm (19.6 ft) Max Loading Height: 6390 mm (21.0 ft) Max Reach Along Ground: 9080 mm (29.8 ft) Max Digging Height: 9170 mm (30.1 ft) |
| Dimensions | Overall Length: 9490 mm (31.1 ft) Overall Width (over tracks): 2850 mm (9.35 ft) Height (top of cab): 2890 mm (9.48 ft) Rear Swing Radius: 2750 mm (9.0 ft) Track Gauge: 2200 mm (7.2 ft) Ground Clearance: 450 mm (1.5 ft) |
| Undercarriage & Travel | Track Shoe Width: 600 mm (23.6 in) Ground Contact Length: 3680 mm (12.1 ft) Ground Pressure: 42.5 kPa (6.16 psi) Max Travel Speed: 5.5 kph (3.4 mph) |
| Capacities | Fuel Tank: 310 L (81.9 US gal) Engine Oil: 25 L (6.6 US gal) Coolant: 22 L (5.8 US gal) |
| Swing Mechanism | Swing Speed: 13.9 rpm |
| Rated Net Power | 99 kW (133 hp) @ 2050 rpm (DIN 6271); 98.4 kW (132 hp) @ 2050 rpm (SAE J1349) |
| Hydraulic Fluid Capacity | 180 L (47.6 US gal) |
| Capacity | 0.8 m³ (1.05 yd³) (heaped); Optional: 0.51-1.2 m³ |
| Engine Oil | 25 L (6.6 US gal) |
Machine Highlights
- Used excavator suitable for construction and earthmoving work
- Practical option for road work, foundation jobs, land development, and general site projects
- Inspection photos, working video, and machine condition details can be provided before purchase
- Export support, loading assistance, and shipping coordination available for overseas buyers
Why Choose This Machine
A well-selected used machine can help reduce equipment costs while still meeting job site requirements. Before shipment, buyers can review key points such as engine condition, hydraulic performance, undercarriage condition, cab condition, working hours, and service details.
Contact Us
Contact CN Used Machinery for the latest price, more photos, working video, inspection details, and shipping information for this used hitachi ex200-2 excavator for sale.
