1 5

HITACHI

USED HITACHI ZX135

USED HITACHI ZX135

$17,000.00 USD
$17,000.00 USD
Sale Sold out

HITACHI ZX135 (ZX135US-5 Base Model) Core Specifications


Category Parameters Details
Engine Make Isuzu
Model 4JJ1X IIIB
Net Power (ISO 9249) 72 kW (97 hp) @ 2000 rpm
Displacement 2.999 L (182 cu.in.)
Max Torque 374 Nm @ 1600 rpm
Operation Operating Weight 14,500 kg (31,967 lbs)
Bucket Capacity (ISO Heaped) 0.3-0.66 m³
Fuel Capacity 220 L (58 gal)
Hydraulic System Fluid Capacity 60 L (15.9 gal)
Swing Speed 13.3 rpm
Max Travel Speed 2.0/3.4 km/h (1.2/2.1 mph)
Ground Pressure 41 kPa (5.95 psi)
Digging Performance Max Digging Depth 5,070 mm (16'8")
Max Digging Reach 8,020 mm (26'4")
Max Cutting Height 7,050 mm (23'1")
Max Dump Height 5,100 mm (16'9")
Digging Force (ISO) Bucket Digging Force 73 kN (16,411 lbs)
Arm Digging Force 52 kN (11,689 lbs)
View full details
