| Engine |
Make |
Isuzu |
|
Model |
4HK1X (turbocharged, intercooled) |
|
Net Power (ISO 9249) |
122 kW (164 hp) @ 2000 rpm |
|
Displacement |
5.193 L (316.9 cu in) |
|
Max Torque |
655 Nm (483 lb-ft) @ 1600 rpm |
| Operation |
Operating Weight |
20,500-21,800 kg (45,195-48,061 lbs) |
|
Bucket Capacity (ISO Heaped) |
0.8-1.2 m³ (1.05-1.57 yd³), standard 1.0 m³ |
|
Fuel Capacity |
400 L (105.7 gal) |
|
Hydraulic System Fluid Capacity |
240 L (63.4 gal) |
|
Swing Speed |
13.3 rpm |
|
Max Travel Speed |
3.5/5.5 km/h (2.2/3.4 mph) |
|
Ground Pressure |
46 kPa (6.67 psi) |
| Digging Performance |
Max Digging Depth |
6,670 mm (21'11") |
|
Max Digging Reach |
9,750 mm (32'0") |
|
Max Cutting Height |
10,050 mm (33'0") |
|
Max Dump Height |
7,100 mm (23'3") |
| Digging Force (ISO) |
Bucket Digging Force |
158 kN (35,520 lbs) |
|
Arm Digging Force |
110 kN (24,729 lbs) |
