| Parameter | Specification |
|---|---|
| Engine Model | Yanmar 3TNV88, 3‑cylinder water‑cooled diesel |
| Net Power | 21.3 kW (28.5 HP) @2200 rpm |
| Displacement | 1.642 L |
| Emission | EU Stage 3A / Tier3 |
| Operating Weight | 3520‑3720 kg (7760‑8200 lb) |
| Standard Bucket Capacity | 0.11 m³ (0.14 yd³), range 0.055‑0.15 m³ |
| Boom / Stick Length | 2400 mm /1320 mm |
| Digging Performance | |
| Bucket Digging Force | 27.5 kN |
| Stick Digging Force | 17.8 kN |
| Max Digging Depth | 3050 mm |
| Max Ground Reach | 5210 mm |
| Max Digging Height | 4710 mm |
| Max Dumping Height | 3320 mm |
| Rear Swing Radius | 870 mm (zero‑tail swing) |
| Hydraulic System | |
| Pump Configuration | 3‑pump system (2 variable +1 gear pump) |
| Main Pump Total Flow | 63.6 L/min |
| Implement Relief Pressure | 24.5 MPa |
| Swing & Travel | |
| Swing Speed | 9.0 rpm |
| Travel Speed Low/High | 2.8 km/h /4.3 km/h |
| Gradeability | 70 % (35°) |
| Undercarriage | |
| Track Shoe Width | 300 mm rubber / steel track |
| Track Gauge | 1440 mm |
| Overall Width | 1740 mm |
| Ground Pressure | 31 kPa |
| Overall Dimensions | |
| Transport Length | 4780 mm |
| Overall Height (Cab Top) | 2490 mm |
| Ground Clearance | 355 mm |
| Service Capacities | |
| Fuel Tank | 70 L |
| Hydraulic Tank | 58 L |
| Engine Oil | 7.2 L |
| Coolant | 6 L |
