| Engine |
Make |
Isuzu |
|
Model |
CC - 4JG1 (ZX60 - 5A) / Yanmar 4TNV98C (ZX60USB - 5N) |
|
Net Power |
42.4 kW (57.6 hp) @ 2100 rpm (ZX60 - 5A); 39.6 kW (53.8 hp) @ 2000 rpm (ZX60USB - 5N) |
|
Displacement |
3.059 L (ZX60 - 5A); 3.3 L (ZX60USB - 5N) |
|
Max Torque |
186 Nm @ 1400 rpm (ZX60 - 5A) |
| Operation |
Operating Weight |
5,960 kg (13,139 lbs) (ZX60 - 5A); 6,090-6,540 kg (13,426-14,418 lbs) (ZX60USB - 5N) |
|
Bucket Capacity (ISO) |
0.24 m³ (ZX60 - 5A); 0.22-0.3 m³ (ZX60USB - 5N) |
|
Fuel Capacity |
120 L (31.7 gal) |
|
Hydraulic System Fluid Capacity |
61 L (16.1 gal) (ZX60 - 5A); 41 L (10.9 gal) (ZX60USB - 5N) |
|
Swing Speed |
9.3 rpm (ZX60 - 5A); 9.5 rpm (ZX60USB - 5N) |
|
Max Travel Speed |
2.5/4.5 km/h (1.6/2.8 mph) |
|
Ground Pressure |
33 kPa (4.8 psi) (ZX60 - 5A); 4.93 psi (ZX60USB - 5N) |
| Digging Performance |
Max Digging Depth |
3,850 mm (12'8") (ZX60 - 5A); 4,120 mm (13'6") (ZX60USB - 5N) |
|
Max Digging Reach |
6,250 mm (20'6") (ZX60 - 5A); 6,560 mm (21'1") (ZX60USB - 5N) |
|
Max Cutting Height |
5,800 mm (19'0") |
|
Max Dump Height |
4,080 mm (13'5") |
| Digging Force (ISO) |
Bucket Digging Force |
41.4 kN (9,307 lbs) |
|
Arm Digging Force |
28.4 kN (6,385 lbs) (ZX60 - 5A); 27.0 kN (6,063 lbs) (ZX60USB - 5N) |
