| Basic Information |
|
| Model |
KOBELCO SK200-8 |
| Engine Model |
Mitsubishi 6D34-TLE2A (6-cylinder, water-cooled, turbocharged with intercooler, direct-injection diesel) |
| Displacement |
6.348 L (387.3 cu in) |
| Net Power |
125 kW (168 HP) @ 2000 rpm (ISO 9249/SAE J1349) |
| Max Torque |
620 N·m (457.3 lb·ft) @ 1600 rpm |
| Operating Weight |
20,100 kg (44,313 lbs) (standard with dozer blade) |
| Standard Bucket Capacity |
0.8 m³ (1.046 cu yd, heaped); 0.64 m³ (0.837 cu yd, struck) |
| Performance Parameters |
|
| Max Travel Speed |
5.5 km/h (3.4 mph, high); 3.3 km/h (2.1 mph, low) |
| Max Digging Depth |
6,020 mm (19.75 ft) |
| Max Digging Height |
9,700 mm (31.82 ft) |
| Max Dumping Height |
6,900 mm (22.64 ft) |
| Max Digging Reach |
9,900 mm (32.48 ft) |
| Swing Speed |
13.3 rpm |
| Bucket Digging Force |
157 kN (15,999 kgf, power boost on) |
| Arm Crowding Force |
112 kN (11,423 kgf, power boost on) |
| Climbing Ability |
35° (70%) |
| Drawbar Pull |
228 kN (23,246 kgf, SAE standard) |
| Dimensions |
|
| Track Width |
600 mm (23.62 in, standard); optional 800 mm (31.50 in) |
| Track Gauge |
2,700 mm (8.86 ft) |
| Overall Length (bucket on ground) |
9,600 mm (31.50 ft) |
| Overall Width |
2,800 mm (9.19 ft) |
| Overall Height (top of cab) |
3,060 mm (10.04 ft) |
| Min Ground Clearance |
450 mm (17.72 in) |
| Rear Swing Radius |
2,200 mm (7.22 ft) |
| Capacities |
|
| Fuel Tank |
320 L (84.5 US gal) |
| Hydraulic System Fluid Capacity |
Approx. 244 L (64.5 US gal) |
| Hydraulic Tank Capacity |
140 L (37.0 US gal) |
| Engine Oil Capacity |
25 L (6.6 US gal) |
| Hydraulic System |
|
| Main Relief Pressure |
34.3 MPa (4,974 psi, boom/arm/bucket/travel); 29.0 MPa (4,206 psi, swing); 37.8 MPa (5,482 psi, power boost) |
| Main Pump Flow |
2 × 220 L/min (2 × 58.12 gpm); pilot pump flow: 20 L/min (5.28 gpm) |
