USED KOBELCO SK390XD-10

USED KOBELCO SK390XD-10

$35,000.00 USD
$35,000.00 USD
Sale Sold out
Parameter Unit Value
Model – KOBELCO SK390XD‑10 (SuperX)
Operating Weight kg 38,800
Standard Bucket Capacity (Heaped) m³ 2.0
Engine Model – Hino J08ETM‑KSDL
Engine Type – 4‑cycle, water‑cooled, turbocharged, after‑cooled, direct injection
Rated Net Power kW (HP) 209 (280)
Rated Engine Speed rpm 2,100
Max. Torque N·m 998 @ 1,600 rpm
Displacement L 7.68
Emission Standard – China Non‑road Stage IV / EPA Tier 4 Final
Swing Speed rpm 7.0
Travel Speed (High) km/h 5.6
Travel Speed (Low) km/h 3.3
Gradeability % 70
Drawbar Pull kN 331
Bucket Digging Force (Std.) kN 224
Arm Digging Force (Std.) kN 201
Max. Digging Radius mm 10,890
Max. Digging Depth mm 7,150
Max. Digging Height mm 10,370
Max. Dumping Height mm 7,190
Overall Transport Length mm 11,440
Overall Transport Width mm 3,190
Overall Transport Height mm 3,860
Standard Track Shoe Width mm 600
Track Gauge mm 2,590
Ground Pressure kPa 78
Fuel Tank Capacity L 503
Hydraulic Tank Capacity L 245
Hydraulic System Capacity L 410
