USED SHANTUI SE60-10W

USED SHANTUI SE60-10W

$10,000.00 USD
$10,000.00 USD
Sale Sold out
Parameter Unit Value
Operating Weight kg 5960
Bucket Capacity m³ 0.25
Engine Model - Weichai WP3.2
Rated Power kW/rpm 36.8/2200
Emission Standard - China Stage IV
Displacement L 3.2
Rated Hydraulic Flow L/min 152
Swing Speed r/min 11
Bucket Digging Force kN 51
Arm Digging Force kN 35.5
Ground Pressure kPa 32
Travel Speed km/h 2.2/4.0
Gradeability - 70% (35°)
Overall Length mm 5870
Overall Width mm 2000
Overall Height (to Cab Top) mm 2675
Min. Ground Clearance mm 370
Track Gauge mm 1600
Track Width mm 400
Max. Digging Radius mm 6140
Max. Digging Depth mm 3780
Max. Digging Height mm 5710
Max. Dumping Height mm 4135
Fuel Tank Capacity L 125
Hydraulic Tank Capacity L 65
