XCMG

USED XCMG XE80D

$13,000.00 USD

Sale Sold out

Item	Specification
Model	XCMG XE80D
Operating Weight	7,730 kg
Standard Bucket Capacity	0.33 m³
Overall Dimensions (L×W×H)	6,215 × 2,280 × 2,690 mm
Track Shoe Width	450 mm
Ground Clearance	373 mm
Tail Swing Radius	1,865 mm
Engine Model	Yanmar 4TNV98‑ZCSXG (4‑cylinder diesel)
Rated Power	44.8 kW @ 2,200 rpm
Max Torque	225.7–245.8 N·m @ 1,650 rpm
Displacement	3.319 L
Emission Standard	China Stage III / Euro Stage III
Fuel Tank Capacity	137 L
Hydraulic Tank Capacity	82 L
Max Digging Depth	4,070 mm
Max Digging Radius	6,245 mm
Max Digging Height	7,120 mm
Max Dumping Height	5,160 mm
Max Vertical Digging Depth	3,120 mm
Bucket Digging Force	57 kN
Arm Digging Force	38 kN
Max Traction Force	68.3 kN
Travel Speed (Low/High)	2.7 / 5.0 km/h
Swing Speed	11 rpm
Gradeability	35°
Ground Pressure	34.85 kPa
